Casali Eradix Root-Barrier

Features
Description
Performance
Projects
Downloads

Features

Key Features

Guaranteed by more than 20 years of use in the field, covered by FLL-EN13948 certification, ecologically compatible – Eradix does not interfere with the growth of plants; easy to apply.

Lab Test	Standard	u.m.	Eradix 40200
Thickness	EN 1849-1	mm	4
Ultimate tensile strength
– Resistance at break – Longitudinal	EN 12311-1	N/5cm	800
– Resistance at break – Transversal	EN 12311-1	N/5cm	800
– Elongation at break – Longitudinal	EN 12311-1	%	45
– Elongation at break – Transversal	EN 12311-1	%	45
Tearing Resistance
– Resistance at break – Longitudinal	EN 12310-1	N	220
– Resistance at break – Transversal	EN 12310-1	N	240
Flexibility at low temperatures	EN 1109	°C	-15
Creeping at heat	EN 1110	°C	+130
Root Proof	EN 13948		Pass

Eradix is a special torch-on 10m² roll root-stop waterproofing membrane for multi-layer green roof solutions especially formulated to protect waterproofing systems from root damage.

The Eradix family of membranes comes from Casali’s research work on special chemical root-stop additives to attain products of absolute excellence for a wide range of project requirements (roof gardens, green roofs, flower beds, ground-laid structures of large and small surfaces).

The compound used in Eradix contains distilled bitumen modified with polypropylene polymer and the Bayer® additive Preventol® B2 which makes the compound an efficient and uniform chemical root-stop barrier, even along the membrane joints. Thanks to the use of reinforcement with high/medium mass per unit area consisting of continuous non-woven polyester, Eradix guarantees good mechanical performance for different types of stress (root pressure, weight of plants and soil, static loads, paths etc).

Top finish in branded polythene or natural slate chips disseminated uniformly and firmly anchored; smooth bottom finish in torched off branded polythene sheets.

Eradix is guaranteed by more than 20 years of use in the field, covered by FLL-EN13948 certification, ecologically compatible - it does not interfere with the growth of plants and is easy to be applied.

Antipodean Apartments

Recently completed, this substantial inner-city residential development encompasses 160 apartments over 14 levels in the vibrant heart of Auckland’s CBD.

ASB Building – North Wharf

In the ASB project, Casali features across the roof expanse of buildings 22 and 23

Auckland Central Library

Auckland Central Library Roof required the refurbishment of existing flat-roof and green-roof installation to preserve the building.

Auckland Zoo – East Asia Precinct

Auckland Zoo is the biggest Zoo in New Zealand. This project was apart of the Zoo’s 10-year re-development plan attempting to transform the zoo.

Bellus Apartments

XXXX

Crest Apartments

The mix development of commercial space, townhouses and 5 levels apartment tower required a robust system of waterproofing for exposed to rain areas at both ground retail level and elevated apartment tower balconies.

Edition Apartments

The Edition Apartments is a residential development located in Parnell, Auckland with 19 apartments. The building comprises of two carpark levels below street grade with the three upper levels cantilevered above the ground floor, retaining breathtaking views of the harbour beyond.

Kaipātiki Road Kāinga Ora Apartments

The Kāinga Ora redevelopment required robust waterproofing solutions for below ground, balconies and planters.

Kings College Performing Arts Centre

Robust waterproofing for Toi Manawa, the brand-new Performing Arts Centre at King’s College

MacMurray Medical Centre

This cutting-edge private medical centre located in the Auckland suburb of Remuera was beautifully designed by Warren & Mahoney Architects to provide a relaxing patient experience, from the consultation suites to the operating rooms and recovery rooms.
